Antminer Z15 (420 KSol/s) APW7 included

€2.975,- VAT excl. €3.599,- VAT incl. Ships out from July 20th - 31st Order now

BITMAIN ANTMINER Z15, Equihash, Exceptional Computing Power, immense energy Savings!

*Your order is only final after we confirmed it by sending the invoice.
*Order without VAT (0%) with a EU company VAT number or by ordering from outside EU
*The price of mining machines must be adjusted frequently according to many factors, including cryptocurrency/USD exchange rate, the network difficulty, expected difficulty increase or changes in the algorithm. Refund requests based on these factors cannot be honored.
*Up to two years warranty instead of 180 days.
*Best EU pricing available!



Antminer Z15 Specifications:

Product Glance

Value

Model No. 240-Z
Crypto Algorithm/Coins

EquiHash/Zcash

Hashrate, KSol/s

420

Reference power on wall, Watt

1510

Reference power efficiency on wall @25°C, J/Ksol

3.60

Adapted AC/DC output requirement, Watt/ Volt

1752/ 12.00



Detailed Characteristics

Value

Min

Typ

Max

Hashrate & Power
Hashrate, KSol/s

420

440

Power efficiency on wall @25°C, J/KSol(1-1)

3.60

3.76

Power efficiency on wall @40°C, J/KSol(1-2)

3.72

3.85

Reference power on wall, Watt (1-3)

1510

1695

DC input voltage range, Volt (1-4)

11.60

12.00

13.00

DC input current range, Amp (1-5)

131


151
Adapted AC/DC output power requirement, Watt (1-6)

1576

1752

Hardware Configuration
Quantity of hash chips

9

Quantity of hash boards

3

Networking connection mode

RJ45 ethernet 10/100M

Miner Size (Length*Width*Height, w/o package),  mm (2-1) 245*132.5*290
Net weight, kg (2-2)

5.90

Noise, dBA @25°C (3-1)

70

Environment Requirements
Operation temperature,°C

0

25

40

Storage temperature,°C

-40

25

85

Operation humidity, RH

5%

95%



Notes:

(1-1) Refers PSU power conversion efficiency of 93%

(1-2) Refers PSU power conversion efficiency of 93%

(1-3) Min condition: 25°C, min J/KSol, typical hashrate

Max condition: 40°C, max J/KSol, max hashrate

Refers PSU power conversion efficiency of 93%

(1-4) Caution: Wrong input voltage may probably cause miner damaged

(1-5) Typ condition: min reference power, typical DC input voltage

Max condition: max reference power, min DC input voltage

(1-6) Min condition: 40°C, max J/KSol, max hashrate,

    PSU output power should be no less than the min value to make sure mining stable.

Typical condition: (typical power) = (min power)/90%, leave power output margin for PSU.

         Caution: It is strongly recommended that using typical power can make sure your miner can work well.

         You can use one PSU to power multiple boards. Do not attempt to power one board with more than one PSU.

         All PCI-E ports are required to plug in while powering up the board.

(2-1) domestic and international version

(2-2) domestic and international version

(3-1) Max condition: Fan is under max RPM(rotation per minute).

You will need an ATX PSU with sufficient 7 six-pin PCIE connectors. All PCIE connectors on a hashing board need to be connected to the PSU for the hashing board to operate.  The APW7 power supply is included to power up the Antminer Z15.
The power cord is not included, please find one with at least 10A from your local market.

Exceptional Computational Power

The Antminer Z15 achieves a remarkable hashing performance of 420 KSol/s, 3X more power compared to its predecessor. Become a leader of the Equihash platform.

Immense Energy Savings

The new chip design and circuit configuration provides an impressive power efficiency of 3.6 J/KSol, saving up to 60%, providing more income to miners.

Enhanced Processing Power & Lightweight

Enhanced performance is attained effortlessly through the processing power of the TSMC 12nm chip. Even though the Antminer Z15 packs in three times more hashing power than the Antminer Z11, at 5.9 kg, it weighs only 0,5 kg more than its predecessor.

An Entirely New Design, Added Safety

A new generation design, effectively prevents dust and improves the stability and safety of the miner.

Antminer Z15

Antminer Z15 back left

Antminer Z15 back right

Antminer Z15 back

Antminer Z15 front

Antminer Z15 front left
